LS408K-0.08X — full specifications, dimensioned drawing and a free datasheet download. Manufactured by CLARIOPTICS with in-house optical design and our own metal factory.
8K Line Scan Lenses (I) - 8K5µm / 8K7µm
| Model | LS408K-0.08X |
|---|---|
| Product family | Line Scan Lenses |
| Series | 8K Line Scan Lenses (I) - 8K5µm / 8K7µm |
| Sensor format | Ø62 |
| Focal length | 40 |
| Aperture range | 4 |
| Magnification | 0.08X |
| Working distance | 524 |
| Mount | M42/M58/M72/F |
| Note | Mag. range 0.07-0.1 |
| Note | WD range 419-586 |
Free to download — no form, no sign-up. Includes full specifications and the dimensioned mechanical drawing. Measured MTF and distortion data is available on request.
Send your camera model, field of view and working distance — we reply with a selection proposal and test data within one business day.
Preview of the official LS408K-0.08X specification sheet — outer dimensions, flange-back, thread sizes and the complete parameter table.
Resolution and distortion figures for the LS408K-0.08X are published in the datasheet above. If you are sizing the lens against a defect size or a measurement tolerance, the two numbers that matter most are the MTF at your sensor Nyquist frequency and the distortion over your actual field of view — both are given in the datasheet.
MTF is measured on an optical transfer function instrument covering 0–500 lp/mm (visible / NIR) and 0–60 lp/mm (LWIR), with on-axis accuracy better than ±2%.
Distortion is controlled across the series; Distortion is measured to better than 0.25% accuracy, so the figure in the datasheet is usable directly in your measurement model.
Production units can ship with a signed test report from our CMA / CNAS accredited optical testing center — specify the test items when you order.
